DIAKAT - BL 300 HD demarcation tiller with Honda engine
Description
The BL-300 is a single-disc sander that has been developed for a wide range of applications.
Thanks to a large selection of tools and a simple quick-change system, most horizontal surfaces can be removed with ease.
The sander offers two versions of tool speed. The low speed of 900 rpm is designed for blocking (removing horizontal ruts).
The high speed of 1,350 rpm is designed for grinding with diamond tools.
Features:
- The simple yet robust design ensures long, trouble-free operation
- High versatility thanks to a wide range of available tools
- Simple operation and adjustment
- Easy transportation and storage thanks to transport position
- Height-adjustable handlebar for greater operating comfort
- Quick-change system for easy replacement of different tools without screws
- Tool cover with dust extraction for compliance with new regulations
- Flexible tool connection, two different models for diamond and carbide tools
Areas of application:
- Milling of concrete and asphalt surfaces
- Removal of ruts
Technical description:
Engine: Honda GVX 160
Power: 3.2 kW
Dimensions: 1260 x 560 x 1020 mm
Weight 113 kg
Motor speed: 3,600 rpm
Spindle speed: 900 / 1350 rpm
Working width: 300 mm
